Advanced Inertial GPS Mouse with Harsh Event Output & High Accurate Odometer
Model: GS501
Inertial GPS Navigation(Ublox 8030, Bosch 6Axis)
Harsh Events Alarm Output:
Harsh Braking
Harsh Accleration
Harsh Cornering
Harsh Lane Depature
Collision
Accurate Speed & Location in Tunnel or Parking Area
No special requirment for Installation Position, Direction or Vehicle
Automatic Calibration
NMEA-0183(GNGGA, GNRMC)
Support GPS, Beidou, Glonass, Galileo
RS232 or TTL Interface, 115200 Baud Rate, 5V DC
Product Parameters
Model | GS501 |
Interface: | RS232 / TTL | Power Supply: | 5V or 12V |
Feature 1 | Automatic Calibration based on Ublox 8030 & Bosch 6 axis G Sensor |
Feature 2 | Accurate location in Parking Lots & Tunnel |
Feature 3 | Any direction or position installation |
Feature 4 | NEMA0183 GNMRC/GNGGA/GNGSA protocol compatible |
Feature 5 | Automatically inertial navigation positioning without GNSS signal |
Harsh Even Alarm: | Harsh Braking, Harsh Acceleration Harsh Cornering Collision Alarm Harsh Lane Departure Alarm |
Electrical Specifications: |
Input voltage: 5V DC Power consumption: Passive - 240mW Active (with antenna) - 480mW Maximum current drain< 25mA Accuracy Horizontal: < 5m (50%), < 8 (90%) Altitude: < 10m (50%), < 16 m (90%) Velocity: < 0.06m/sec = 0.22km/h | Acquisitions After loss of lock: < 2s (90%) First time power applied: < 38s (50%), < 42s (90%) Temporary loss of power: < 10s (50%), < 13s (90%) Operational Limits Altitude: 18000m Speed: Max300KM/H |
Site Test
![](https://sc04.alicdn.com/kf/U20a8d6eeb0ed421cb9068ef233217bcbC/220951307/U20a8d6eeb0ed421cb9068ef233217bcbC.png)
![](https://sc04.alicdn.com/kf/Ub91207f8ecfa4b05950d5170437354bdL/220951307/Ub91207f8ecfa4b05950d5170437354bdL.jpg)
![](https://sc04.alicdn.com/kf/Uc7dea4aa96c648ec8994ae12d89dc2dbK/220951307/Uc7dea4aa96c648ec8994ae12d89dc2dbK.jpg)
Details Images
![](https://sc04.alicdn.com/kf/Hb7475cfc4c874e1ba5c74f7245a8c81cF/220951307/Hb7475cfc4c874e1ba5c74f7245a8c81cF.jpg)
![](https://sc04.alicdn.com/kf/Hef71bbe86b064824a369cbe266ca4c3bV/220951307/Hef71bbe86b064824a369cbe266ca4c3bV.png)
